The aerial work vehicle adopts folding curved arm structure. The working arm is three section folding type. The working bucket and turntable are in duplex position. It is operated up and down. It is controlled by hydraulic manual control. It can rotate 360 degrees. It has four hydraulic legs, with hook, steel tool box, coaming plate and anti-skid tread plate.

1. The working bucket adopts mechanical self balance design, and its function is that the working bucket is always in a state of balance. The jib has a larger extension angle of 65 ° to adjust to a better working position. (jib extension angle measurement methods are different, some manufacturers mark it as 90 °)

2. The upper and lower two sets of operating systems can complete all kinds of operations on the platform and turntable.

3. Night operation lamp, operation lamp can be selected on the operation desk according to the customer's operation environment, which makes night operation safer.

4. The outrigger can be adjusted independently, and each outrigger can be adjusted independently according to the working ground environment. Even if the ground is uneven, the whole vehicle can be adjusted to a stable state.

5. The outrigger adopts the front and rear H-shaped structure, which has larger stress surface and higher stability, and can prevent the deformation or fracture of the beam (Note: for example, the front V-shaped and rear H-shaped outrigger is easy to cause the deformation or fracture of the beam due to the upside down of the head after long-time use).

6. Four vertical outrigger cylinders and upper arm, lower arm and small arm cylinders are all equipped with two-way hydraulic lock. Its function is to lock the cylinder when the cylinder reaches the required position, so as to prevent accidents. The working arm is equipped with a two-way balance valve to make the working arm run more smoothly.
